Printing technology

Direct Thermal

Print resolution

203 dpi

Print speed (Depends on the media used.)

Maximum 152 mm/sec
(Under Brother standard environment)

Maximum print width

54 mm

Maximum print length

1 m

Minimum print length

12.7 mm

Weight (including battery)

Approximately 545 g

Dimensions

Approximately 100 (D) × 151 (W) × 73 (H) mm

USB

USB Ver. 2.0 (Full Speed) (mini-B)

Bluetooth

Ver 2.1 + EDR
Supported profiles: SPP, OPP, BIP, HCRP
Supported protocol: iAP

Wireless LAN

IEEE 802.11g/n (Wireless Direct)
IEEE 802.11b/g/n (Infrastructure Mode)
IEEE 802.11b/g/n (Ad-hoc Mode)

Operating temperature

Operate: -10°C to 50°C
Charge: 0°C to 40°C

Operating humidity

10% to 90%
(No condensation, Maximum wet bulb temperature: 27°C)

Storage temperature

-20°C to 60°C

Storage humidity

10% to 90%
(No condensation, Maximum wet bulb temperature: 45°C)

Battery

Rechargeable Li-ion battery: 7.2 V

Adapter (optional)

AC adapter (15 V)

Car adapter (optional)

Cigarette lighter car adapter (12 V (DC))

Maximum number of labels

6,400 labels (for continuous printing when connected using USB and using a new, fully charged rechargeable Li-ion battery)
Tested using Brother's print test data (13% coverage, 51 × 25.4 mm) at 23°C.

Charging time

3 hours (when charging at 23°C with the printer turned off, and using a new rechargeable Li-ion battery)

Media type

Receipt, Label

Media width

25.4 mm to 58 mm

Gap between labels

3 mm or more

Thickness

Receipt: 0.058 mm to 0.090 mm
Label: 0.080 mm to 0.170 mm

Roll outside diameter (max)

60 mm

Core diameter (min)

Receipt, Label: 10.2 mm

Media sensor

Transmissive, Reflective
